Coastline Detection Based on Sentinel-1 Time-Series for Ship and Flood Monitoring Applications

Posted on 23 July, 20209 September, 2020 by Carlos López-Martínez in Publication

R. Pelich, M. Chini, R. Hostache, P. Matgen and C. López-Martínez, “Coastline Detection Based on Sentinel-1 Time Series for Ship- and Flood-Monitoring Applications,” in IEEE Geoscience and Remote Sensing Letters, Early Access, 2020

➲ Full paper

Summary

This letter addresses the use of the Sentinel-1 time series with the aim of proposing an automatic and unsupervised coastline detection method that averages the dynamical variations of coastal areas over a limited period of time, e.g., one year. First, we propose applying a temporal averaging filter that allows the temporal variations in coastal areas, e.g., due to tides or vegetation, to be encapsulated, and, at the same time, the speckle to be reduced, without decreasing the spatial resolution of the synthetic aperture radar (SAR) time series. Then, based on the distinctive backscattering values of the sea and land pixels, we will employ an iterative hierarchical tiling method in order to accurately characterize the two classes using bimodal distribution. The distribution is then segmented by a thresholding and region-growing procedure to separate the sea and land classes. A large-scale quantitative comparison between the SAR-derived and open street map (OSM) coastlines allows for a numerical evaluation of the results, i.e., an overall agreement ranging from 80% to 90%. In addition, Sentinel-2 images are used to evaluate the estimated SAR coastline qualitatively. Furthermore, the benefits of having an accurate SAR coastline are shown in the case of two well-known Earth observation-monitoring applications, ship detection, and floodwater mapping.

Estimation of Vegetation Structure Parameters From SMAP Radar Intensity Observations

Posted on 24 May, 20209 September, 2020 by Carlos López-Martínez in Publication

T. Jagdhuber, C. Montzka, C. López-Martínez, M. J. Baur, M. Link, M. Piles, N. N. Das and F. Jonard, “Estimation of Vegetation Structure Parameters From SMAP Radar Intensity Observations,” in IEEE Transactions on Geoscience and Remote Sensing, Early Access, 2020

➲ Full paper

Summary

In this article, we present a multipolarimetric estimation approach for two model-based vegetation structure parameters (shape AP and orientation distribution $\Psi$ of the main canopy elements). The approach is based on a reduced observation set of three incoherent (no phase information) polarimetric backscatter intensities ( $|S_{hh}|^2$ , $|S_{hv}|^2$ , and $|S_{vv}|^2$ ) combined with a two-parameter (AP and $\Psi$ ) discrete scatterer model of vegetation. The objective is to understand whether this confined set of observations contains enough information to estimate the two vegetation structure parameters from the L-band radar signals. In order to disentangle soil and vegetation scattering influences on these signals and ultimately perform a vegetation-only retrieval of vegetation shape AP and orientation distribution $\Psi$ , we use the subpixel spatial heterogeneity expressed by the covariation of co- and cross-polarized backscatter $\Gamma_{PP-PQ}$ of the neighboring cells and assume it is indicative for the amount of a vegetation-only co-to-cross-polarized backscatter ratio $\mu_{PP-PQ}$ . The ratio-based retrieval approach enables a relative (no absolute backscatter) estimation of the vegetation structure parameters which is more robust compared to retrievals with absolute terms. The application of the developed algorithm on global L-band Soil Moisture Active Passive (SMAP) radar data acquired from April to July 2015 indicates the potential and limitations of estimating these two parameters when no fully polarimetric data are available. A focus study on six different regions of interest, spanning land cover from barren land to tropical rainforest, shows a steady increase in orientation distribution toward randomly oriented volumes and a continuous decrease in shape arriving at dipoles for tropical vegetation. A comparison with independent data sets of vegetation height and above-ground biomass confirms this consistent and meaningful retrieval of AP and $\Psi$ . The retrieved shapes and orientation distributions represent the main vegetation elements matching the literature results from model-based decompositions of fully polarimetric L-band data at the SMAP spatial resolution. Based on our findings, AP and $\Psi$ can be directly applied for parameterizing the vegetation scattering component of model-based polarimetric decompositions. This should facilitate decomposition into ground and vegetation scattering components and improve the retrieval of soil parameters (moisture and roughness) under vegetation.

Large-Scale automatic vessel monitoring based on dual-polarization Sentinel-1 and AIS data

Posted on 7 May, 20199 September, 2020 by Carlos López-Martínez in Publication

Pelich, R.; Chini, M.; Hostache, R.; Matgen, P.; Lopez-Martinez, C.; Nuevo, M.; Ries, P.; Eiden, G. “Large-Scale Automatic Vessel Monitoring Based on Dual-Polarization Sentinel-1 and AIS Data”. Remote Sens. 2019, 11, 1078.

➲ Open access full paper

Summary

This research addresses the use of dual-polarimetric descriptors for automatic large-scale ship detection and characterization from synthetic aperture radar (SAR) data. Ship detection is usually performed independently on each polarization channel and the detection results are merged subsequently. In this study, we propose to make use of the complex coherence between the two polarization channels of Sentinel-1 and to perform vessel detection in this domain. Therefore, an automatic algorithm, based on the dual-polarization coherence, and applicable to entire large scale SAR scenes in a timely manner, is developed. Automatic identification system (AIS) data are used for an extensive and also large scale cross-comparison with the SAR-based detections. The comparative assessment allows us to evaluate the added-value of the dual-polarization complex coherence, with respect to SAR intensity images in ship detection, as well as the SAR detection performances depending on a vessel’s size. The proposed methodology is justified statistically and tested on Sentinel-1 data acquired over two different and contrasting, in terms of traffic conditions, areas: the English Channel the and Pacific coastline of Mexico. The results indicate a very high SAR detection rate, i.e., >80%, for vessels larger than 60 m and a decrease of detection rate up to 40% for smaller size vessels. In addition, the analysis highlights many SAR detections without corresponding AIS positions, indicating the complementarity of SAR with respect to cooperative sources for detecting dark vessels.

Towards a 20 m Global Building Map from Sentinel-1 SAR Data

Posted on 19 November, 20189 September, 2020 by Carlos López-Martínez in Publication

Chini, M.; Pelich, R.; Hostache, R.; Matgen, P.; Lopez-Martinez, C. “Towards a 20 m Global Building Map from Sentinel-1 SAR Data”. Remote Sens. 2018, 10, 1833.

➲ Open access full paper

Summary

This study introduces a technique for automatically mapping built-up areas using synthetic aperture radar (SAR) backscattering intensity and interferometric multi-temporal coherence generated from Sentinel-1 data in the framework of the Copernicus program. The underlying hypothesis is that, in SAR images, built-up areas exhibit very high backscattering values that are coherent in time. Several particular characteristics of the Sentinel-1 satellite mission are put to good use, such as its high revisit time, the availability of dual-polarized data, and its small orbital tube. The newly developed algorithm is based on an adaptive parametric thresholding that first identifies pixels with high backscattering values in both VV and VH polarimetric channels. The interferometric SAR coherence is then used to reduce false alarms. These are caused by land cover classes (other than buildings) that are characterized by high backscattering values that are not coherent in time (e.g., certain types of vegetated areas). The algorithm was tested on Sentinel-1 Interferometric Wide Swath data from five different test sites located in semiarid and arid regions in the Mediterranean region and Northern Africa. The resulting building maps were compared with the Global Urban Footprint (GUF) derived from the TerraSAR-X mission data and, on average, a 92% agreement was obtained.
